Prepare the Subfloor — Dry Fit the Shower Pan
Part of project
How to Install and Level a Shower Pan Base · Step 3 of 9
In this video
The first step is to prepare the area for the shower pan. This involves a 'dry fit' where the pan is placed in the shower stall to check for any issues. In this case, the drain hole lines up directly with a floor joist. To fix this, a section of the subfloor is cut out using a reciprocating saw. The obstructing joist is then cut and new support blocking is framed in to reinforce the structure. A new piece of plywood is cut with a jigsaw to patch the hole in the subfloor. Finally, the entire area is swept clean to prepare for the mortar bed.
Goal: Create a clean, structurally sound subfloor with drain clearance
- Modifying floor joists is a structural change. If you are not experienced, consult a professional. Ensure new framing provides adequate support.
Used in this video
- Reciprocating Saw (brand: Ryobi, Tool Type: Reciprocating Saw, Power Source: Battery) — Cutting the existing subfloor and floor joist.
- Jigsaw (brand: Unspecified, Tool Type: Jigsaw, Power Source: Corded) — Cutting the new plywood patch for the subfloor.
- Drill (brand: DeWalt, Tool Type: Drill, Power Source: Battery) — Driving screws to install new framing.
- Broom (brand: Unspecified, Tool Type: Hand Tools, Power Source: Manual) — Sweeping the subfloor clean.
- Plywood (Material: Wood, Material Type: Plywood) — Patching the hole in the subfloor.
- Lumber (2x stock) (Material: Wood, Material Type: Lumber) — Creating new support framing for the subfloor.
- Wood Screws (Material: Metal, Supply Type: Hardware) — Fastening the new framing.
278K subscribers
FAQs
What is the most critical step to ensure a leak-free shower pan installation?
The most critical steps involve a thorough dry fit to confirm proper drain alignment and a securely sealed drain connection. Ensure the pan is set in a complete and solid bed of mortar, and all plumbing connections are sealed with appropriate compounds for long-term integrity.
How important is it to perfectly level the shower pan, and what happens if it's not?
Perfect leveling is crucial for proper water drainage. If the pan isn't perfectly level, water will pool in low spots instead of flowing to the drain, leading to mold, mildew, and potential subfloor damage. Use a reliable level and check it from multiple angles during the dry fit and after setting the pan.
What type of mortar should I use for setting the shower pan, and how do I mix it?
Use Type S mortar, like the Greencore 65 lbs. Type S Mortar listed, as it offers superior strength and bonding. Mix it according to the manufacturer's instructions to achieve a thick, peanut-butter-like consistency that is workable but firm enough to hold the pan's position without slumping.
What safety precautions should I take when installing a shower pan, especially regarding dust and materials?
Always wear work gloves, safety glasses, and a dust mask (such as the Dyiom or Paitning mask mentioned) when mixing mortar, cleaning the subfloor, or cutting materials. Ensure your work area is well-ventilated to minimize inhaling dust and chemical fumes for your safety.
