Mount the Filter Housing — Plan and Prepare
Part of project
How to Install a Whole-House Sediment Water Filter · Step 1 of 7
In this video
Choose a suitable location on the cabinet wall under the sink to mount the filter head. Ensure there is enough clearance below to easily change the filter cartridge in the future. Remove the top cap of the housing. Use a screwdriver to install the first mounting screw, hang the housing on it, and then install the second screw to secure it firmly to the wall. Replace the cap.
Goal: Mount the filter head unit inside the cabinet.
- Pick a spot with easy access for future filter changes.
Used in this video
- Screwdriver — Driving the mounting screws into the cabinet wall.
3K subscribers
FAQs
What makes this whole-house filter installation "intermediate" difficulty, and what are the trickiest parts for a DIYer?
The "intermediate" rating comes from working with pressurized plumbing, requiring precise pipe cutting, and ensuring leak-free compression fittings. Beginners often find accurately measuring and cutting the main line, along with properly tightening fittings without over-tightening, to be the most challenging aspects.
Are the specialized pipe cutting tools like the RIDGID 104 or AUTOCUT 1/2 in. cutter truly necessary, or can I use a standard hacksaw?
Specialized tubing cutters are highly recommended for clean, straight cuts on copper pipe, which is crucial for a secure, leak-free connection with compression fittings. A hacksaw can leave burrs and uneven edges, significantly increasing the risk of leaks, making extra deburring and cleaning essential if used.
What are the most common mistakes that lead to leaks during this filter installation, and how can I avoid them?
The most common mistakes include uneven pipe cuts, insufficient deburring, improper application of Teflon tape, and over-tightening or under-tightening compression fittings. To avoid leaks, ensure perfectly straight and burr-free pipe ends, apply Teflon tape clockwise on male threads, and tighten compression fittings just enough to seal, often with a final quarter to half turn past hand-tight.
Why is a bypass loop an essential component for this whole-house filter system, and can I install one without it?
A bypass loop allows you to isolate the filter system for cartridge changes or maintenance without shutting off your entire home's water supply. While technically you could install it without a bypass, it's strongly advised against, as it means you'd have no running water during filter service or if the filter housing needed repair.
