Adjust water pressure — Adjust or Replace the Pressure Regulator

Beginner3 hours

Part of project

Boost Home Water Pressure: A Step-by-Step Guide to Improved Water Flow · Step 2 of 2

Helpful?

In this video

Turn the water supply back on to the system, and adjust the pressure on the PRV by tightening or loosening the adjusting screw with a wrench, checking the pressure using the gauge.

Goal: Adjust PRV to regulate water pressure

Used in this video

  • Wrench (Tool Type: Adjustable wrench, Power Source: Manual, Material Compatibility: Brass, Size/Capacity: Small, Durability: High, Cost: Low) — Turning the adjusting screw to increase or decrease pressure.
1.4M views7.5K10 minutes
Roger Wakefield Plumbing Education

672K subscribers

View Channel

FAQs

What specific tools are essential for accurately checking my home's water pressure?

You'll primarily need a water pressure gauge, such as the Water Source Water Test Pressure Gauge WSPGH100, which easily attaches to an outdoor hose bibb. For adjusting or replacing a pressure regulator, an adjustable wrench and a pipe wrench (e.g., Crescent 12 in. Self-Adjusting Straight Pipe Wrench) are also necessary.

What is the most critical safety step I must take before attempting to adjust or replace my pressure regulator?

Always, without exception, shut off your home's main water supply before making any adjustments or replacements to the pressure regulator. This prevents water leaks, potential flooding, and allows for safe work on your plumbing system. Locate your main shut-off valve, typically near your water meter or where the main line enters your house.

How do I know if my low water pressure issue is definitely due to the pressure regulator and not something else?

Start by checking your main water pressure with a gauge; if it's consistently below the ideal 40-60 psi, your regulator is a prime suspect. However, if the gauge reading is good but pressure is low only in certain areas, the issue might be individual fixture aerators, internal pipe clogs, or issues specific to hot water, which this project doesn't cover.

My pressure regulator looks old or damaged; how do I know if it needs replacement instead of just adjustment?

Signs of a failing regulator include constant pressure fluctuations, banging noises in pipes (water hammer), visible leaks from the regulator itself, or if adjusting it yields no change in pressure. If the regulator is very old (over 10-12 years) or shows significant corrosion, replacement is generally recommended over attempting an adjustment.

Transcript
Hide

valve right here now to adjust these it's pretty straightforward the screw on top here is your adjustment screw that essentially compresses a spring to regulate the amount of pressure that's desired and there's a nut to lock it in place once you got it so let's say we want a balanced 50 psi in our system this particular prv is pre-adjusted at 45 psi so we need to tighten the adjustment screw to increase the pressure up five psi so just unlock the nut give it a turn or two and recheck the pressure on the gauge up until it reaches 50 and you'd lock the nut back in place now

Auto-generated transcript. May contain errors.
