Step 6 · Connect the Drain Pipe

With the pan now set and secured, complete the final drain connection. The method depends on the type of drain assembly. For a compression-style drain, simply push the rubber compression gasket over the drain pipe and then tighten the compression nut on the drain assembly to seal it. For a solvent-weld (glue-on) drain, clean the inside of the drain fitting and the outside of the drain pipe with PVC primer, then apply PVC cement to both surfaces and quickly join them together, holding for 30 seconds. Regardless of the method, ensure a secure, leak-proof connection as per the drain kit's instructions.

Stesso
BrowseMy Projects
Sign in

Step 6 · Connect the Drain Pipe

With the pan now set and secured, complete the final drain connection. The method depends on the type of drain assembly. For a compression-style drain, simply push the rubber compression gasket over the drain pipe and then tighten the compression nut on the drain assembly to seal it. For a solvent-weld (glue-on) drain, clean the inside of the drain fitting and the outside of the drain pipe with PVC primer, then apply PVC cement to both surfaces and quickly join them together, holding for 30 seconds. Regardless of the method, ensure a secure, leak-proof connection as per the drain kit's instructions.

Tools and Materials

← Project

How to Install and Level a Shower Pan Base

Step 6 of 7·20 min left

Subfloor Preparation and Dry Fit
45 mins6 itemsIntermediate
Install the Drain Fitting
20 mins6 itemsIntermediate
Prepare the Mortar Bed
20 mins9 itemsIntermediate
Apply Mortar and Set the Pan
15 mins7 items
Level and Secure the Pan
20 mins3 itemsAdvanced
6
Connect the Drain Pipe
15 mins6 itemsAdvanced
7
Curing and Final Checks
5 mins1 itemsBeginner
