Connect Plumbing — Measure Pipes and Valves
Part of project
How to Install an ADA-Compliant Under-Sink Plumbing Shield · Step 2 of 6
In this video
Connect the flexible, braided water supply lines from the faucet to the corresponding hot and cold angle stops. Hand-tighten the nuts first, then give them a slight turn with a wrench to secure them. Assemble the P-trap and connect it between the sink's drain tailpiece and the wall adapter. Finally, connect the faucet's pop-up drain linkage by attaching the lift rod to the drain lever strap with the provided clip.
Goal: Connect the water supply lines, P-trap, and pop-up drain.
- Hand-tighten all plastic drain parts to avoid cross-threading, then use channel-lock pliers for a final quarter-turn if needed.
- Do not overtighten the water supply line nuts, as this can crack the plastic fittings or damage the rubber gasket, causing a leak.
Used in this video
- Screwdriver — Tightening the screw on the pop-up drain linkage.
- Wrench — Snugging the water supply line connections.
2.2M subscribers
FAQs
Why is installing an ADA-compliant under-sink shield important, and what does "ADA-compliant" mean in this context?
This shield is crucial for preventing contact with hot drain pipes and sharp edges, protecting individuals, especially those using wheelchairs, from burns or abrasions. "ADA-compliant" means it meets specific requirements for clear under-sink space and protection, ensuring accessibility and safety for all users.
This project is rated "beginner" and "3 hours." What's the most challenging part, and what commonly makes it take longer than expected?
The most challenging part is often precisely measuring and trimming the shield components to fit your specific plumbing configuration. Unexpected issues like corroded pipes, tight spaces, or needing to replace an old P-trap can extend the estimated 3-hour completion time. Always double-check measurements before making cuts.
Do I need specialized plumbing tools for this installation, or will standard household tools suffice?
You primarily need basic tools like a utility knife for trimming the shield, a measuring tape, and a marking pencil. While a pail is essential for catching water when working with the P-trap, no highly specialized plumbing tools are typically required if your existing plumbing is in good condition and only needs a shield.
What are the most common mistakes beginners make when installing these shields, and how can I avoid them?
Common mistakes include inaccurate measuring leading to ill-fitting shields and not securely attaching all components. To avoid this, meticulously measure twice before cutting, dry-fit the shields before final attachment, and ensure all straps or fasteners are tightened properly according to the manufacturer's instructions.
