Install Overflow Assembly — Preparation and Tool Gathering
Part of project
How to Replace a Bathtub Overflow Drain Gasket · Step 1 of 7
In this video
After a dry fit has confirmed measurements, remove the overflow assembly from the tub wall. Apply a continuous bead of silicone sealant to the groove on the back of the overflow gasket. Reposition the overflow assembly behind the tub's overflow hole. From inside the tub, insert the black plastic alignment tool through the overflow hole and into the overflow assembly. Place the metal flange ring over the alignment tool and secure the entire assembly by tightening the two provided Phillips head screws.
Goal: Secure and seal the overflow drain component to the bathtub.
- Using the provided alignment tool ensures the overflow is correctly positioned before tightening the screws.
Used in this video
- Phillips Head Screwdriver (Tool Type: Screwdriver, Screwdriver_Type: Phillips) — Tightening the flange screws to secure the overflow assembly.
- Overflow Alignment Tool (brand: Kohler, Material: Plastic) — To correctly align the overflow assembly with the hole in the tub during installation.
- Overflow Flange Ring (brand: Kohler, Material: Metal) — To secure the overflow assembly from inside the tub.
54K subscribers
FAQs
What's the most crucial step to ensure the new gasket creates a truly watertight seal?
The most crucial step is thoroughly cleaning the mating surfaces where the gasket sits. Remove all old caulk, soap scum, and debris using isopropyl alcohol and a putty knife to ensure a smooth, clean surface. This allows the new gasket to adhere perfectly and prevents leaks immediately after installation.
What should I do if the old overflow cover plate screws are stripped, rusted, or won't come out easily?
If the screws are stripped, try using a screw extractor kit or needle-nose pliers to grip and turn them. For rusted screws, apply penetrating oil and let it sit for a while before attempting removal. If all else fails, you may need to carefully drill out the screws and replace them with new ones when installing the overflow plate, which often comes with a new kit.
Can I just apply silicone caulk around the overflow plate instead of replacing the internal gasket?
While caulk might offer a temporary cosmetic seal, it is not a substitute for a properly functioning internal gasket. The gasket creates a flexible, internal watertight seal against the tub wall, which caulk cannot replicate effectively for the long term. Always replace the gasket for a durable and reliable seal from the inside out.
How can I confirm that the new gasket is properly sealed and won't leak after everything is reassembled?
After re-installing the overflow cover plate, fill the tub with water past the overflow opening. Let it sit for at least 15-30 minutes, periodically checking underneath the tub (if accessible) and around the overflow plate for any drips or moisture. This crucial 'Test for Leaks' step confirms your work is watertight.
