Before starting any work, gather all the necessary tools and supplies. This ensures the project proceeds smoothly without interruptions. You will need your new shower arm kit, which typically includes the arm, a matching flange (escutcheon), and a shower head. You will also need thread sealant tape (commonly known as Teflon tape), an adjustable wrench or channel-lock pliers, a soft rag to protect finishes, and a small wire brush for cleaning.
Step 1
⏱ 2 minGather Tools and Materials
Step 2
⏱ 2 min
Remove the Old Shower Head
Begin by removing the old shower head. In most cases, it can be unscrewed by hand by turning it counter-clockwise. If it is too tight due to mineral buildup or age, wrap a soft rag around the shower head's connector nut and use an adjustable wrench or channel-lock pliers to grip it. Turn counter-clockwise to loosen and remove it from the old shower arm.
Step 3
⏱ 2 min
Remove the Old Shower Arm and Flange
With the shower head removed, you can now remove the old shower arm. First, pull the decorative flange (escutcheon) away from the wall to expose the connection point. The arm is simply threaded into a fitting in the wall. Grasp the arm firmly and turn it counter-clockwise to unscrew it. If it's too tight to turn by hand, you can insert the handle of a pair of pliers or a screwdriver into the open end of the arm to use as a lever. Turn it counter-clockwise until it's free from the wall fitting.
Step 4
⏱ 2 min
Clean the Wall Fitting Threads
Once the old arm is removed, inspect the female threads inside the wall fitting (this is called a drop-ear elbow). It will likely have old plumber's tape, pipe dope, or mineral deposits. It is crucial to clean these threads thoroughly. Use a small wire brush or a pick to gently scrape out all the old debris. Finish by wiping the threads clean with a rag. A clean threaded surface is essential for creating a new, watertight seal.
Step 5
⏱ 2 min
Prepare and Wrap the New Shower Arm
Take your new shower arm and identify the shorter threaded end that will go into the wall. Take the plumber's tape (Teflon tape) and wrap it tightly around these threads. You must wrap the tape in a clockwise direction (the same direction you will turn the arm to tighten it). This prevents the tape from unravelling during installation. Apply 3 to 5 full wraps of tape, ensuring the threads are covered but the opening of the pipe is not blocked. Smooth the tape down with your finger.
Step 6
⏱ 2 min
Install the New Shower Arm
Before threading the arm into the wall, slide the new flange (escutcheon) over the arm with its finished side facing what will be the outside. Now, carefully thread the prepared arm into the wall fitting by hand, turning it clockwise. Continue to hand-tighten until it is snug. The arm needs to end up pointing downwards at the correct angle (usually about 45 degrees). If you cannot get it to the right position by hand, use your wrench (with a protective rag) to turn it the final amount. Do not over-tighten. The goal is snug and correctly positioned, not maximum tightness.
Step 7
⏱ 2 minInstall New Shower Head and Test for Leaks
Wrap 2-3 layers of plumber's tape clockwise on the threads at the outer end of the newly installed shower arm. Screw the new shower head on by hand until it is snug. Turn on the shower's water valve and carefully inspect the connections at both the wall and the shower head for any drips or leaks. If a small leak is present at the wall connection, give the arm a very slight (1/8 turn) tightening. If the shower head connection leaks, tighten it a little more by hand or with a rag-protected wrench. Once you've confirmed there are no leaks, slide the flange flush against the wall. A small dab of silicone caulk behind the flange can provide a watertight seal against the wall, but is optional.
