Step 4 · Install Compression Fittings on Tubing

Take one of the cut ends of the water line. Slide a compression nut from your kit onto the tubing, ensuring the threaded side faces the end of the tube. After the nut, slide on the brass or plastic ferrule (also called a sleeve). The tapered end of the ferrule should face the end of the tube. Push the nut and ferrule about 1/2 inch down the tubing. Repeat this exact process on the other cut end of the water line. Both ends should now be prepped with a nut and a ferrule, ready to connect to the filter.

Stesso
BrowseMy Projects
Sign in

Step 4 · Install Compression Fittings on Tubing

Take one of the cut ends of the water line. Slide a compression nut from your kit onto the tubing, ensuring the threaded side faces the end of the tube. After the nut, slide on the brass or plastic ferrule (also called a sleeve). The tapered end of the ferrule should face the end of the tube. Push the nut and ferrule about 1/2 inch down the tubing. Repeat this exact process on the other cut end of the water line. Both ends should now be prepped with a nut and a ferrule, ready to connect to the filter.

Tools and Materials

← Project

How to Install an In-Line Water Filter for a Refrigerator Ice Maker

Step 4 of 7·25 min left

Gather Tools and Materials
5 mins5 itemsBeginner
Shut Off Water Supply and Prepare Area
10 mins2 itemsIntermediate
Cut the Water Line
5 mins3 itemsIntermediate
4
Install Compression Fittings on Tubing
5 mins3 itemsIntermediate
5
Connect Filter to Water Line
10 mins3 itemsAdvanced
6
Turn On Water and Check for Leaks
5 mins2 itemsIntermediate
7
Flush Filter and Finalize
5 mins1 itemsBeginner
