Step 3 · Mark Mounting Hole Locations

Determine the final height of the sink (standard is 32-34 inches from the floor to the rim). Place the pedestal in its final location. Carefully set the sink basin on top of the pedestal. Press the sink basin level against the wall. Use a torpedo level to ensure the basin is level both side-to-side and front-to-back. Once level, trace the outline of the back of the sink basin onto the wall with a pencil. Also, mark the locations of the mounting holes through the back of the sink. Set the sink and pedestal aside. Use a stud finder to locate the wood studs behind the marked hole locations. If the holes line up with studs, drill pilot holes appropriately sized for the lag screws provided with the sink. If they do not align with studs, you will need to install a wood cross-brace behind the drywall, which is a more advanced task. For this guide, we assume alignment with studs.

Stesso
BrowseMy Projects
Sign in

Step 3 · Mark Mounting Hole Locations

Determine the final height of the sink (standard is 32-34 inches from the floor to the rim). Place the pedestal in its final location. Carefully set the sink basin on top of the pedestal. Press the sink basin level against the wall. Use a torpedo level to ensure the basin is level both side-to-side and front-to-back. Once level, trace the outline of the back of the sink basin onto the wall with a pencil. Also, mark the locations of the mounting holes through the back of the sink. Set the sink and pedestal aside. Use a stud finder to locate the wood studs behind the marked hole locations. If the holes line up with studs, drill pilot holes appropriately sized for the lag screws provided with the sink. If they do not align with studs, you will need to install a wood cross-brace behind the drywall, which is a more advanced task. For this guide, we assume alignment with studs.

Tools and Materials

← Project

How to Install a Pedestal Sink

Step 3 of 8·2 hr left

Preparation and Removal of Old Sink
45 mins8 itemsIntermediate
Assemble Faucet and Drain on Basin
30 mins8 itemsAdvanced
3
Mark Mounting Hole Locations
30 mins8 itemsAdvanced
4
Mount the Sink Basin
20 mins5 itemsAdvanced
5
Position Pedestal and Secure Basin
15 mins4 itemsIntermediate
6
Connect the P-Trap and Drain
20 mins2 itemsIntermediate
7
Connect Water Supply Lines
15 mins2 itemsIntermediate
8
Test for Leaks and Apply Caulk
20 mins5 itemsBeginner
